1-1/2AGE 13HX Portable Pump
1-1/2AGE 13HX Portable Pump
High pressure, low volume, gear driven, engine mounted
Documents & Downloads
PDF Drawings
DWG Drawings
Performance Curves
Operation Manuals
Sales Flyers
Performance
Standard Stock ratio2.45:1 gear ratio performance
- 23 GPM @ 225 PSI
- 100 GPM @ 85 PSI
- 120 GPM @ 60 PSI
Also available with: 2.03:1 gear ratio performance:
- 23 GPM @ 175 PSI
- 100 GPM @ 105 PSI
- 120 GPM @ 75 PSI
Features
- Electric start with recoil rope backup
- Bronze impeller and wear rings
- Stainless steel shaft
- Mechanical seal
- Mounting base
- Hard anodized aluminum alloy pump casing
- Aluminum alloy gear case and engine adapter
- Heat-treated alloy steel helical gears
- Ball bearing construction pump and engine
- 2″ NPT suction
- 1-1/2″ NPT flanged discharge
- 2+ hours of runtime per tankful of fuel at 23 GPM @ 175 psi
- 2.45:1 gear ratio
- Discharge pressure gauge
Engine
Honda GX390: 13 hp, 4-stroke, single cylinder OHV, ball bearing supported crank shaft, 6.4 qt. gas tank, 12-volt starter, 3 amp regulated alternator, electric start with recoil rope start back-up.
Weight
150 lbs. (68 kg)
Dimensions
23.5″L x 20″W x 19.25″H
Applications
- Brush truck
- Wildland/attack fire suppression
- Booster reel
Options
N/A
Technology
N/A
